Spring MVC 详解
概述
Spring MVC 是 Spring Framework 的一个核心模块，它实现了 Model-View-Controller (MVC) 设计模式，为构建 Web 应用程序提供了一个灵活且功能强大的框架。Spring MVC 基于 Servlet API 构建，采用了前端控制器模式，通过 DispatcherServlet 作为中央调度器来处理所有的 HTTP 请求。
目录
MVC 架构模式
1. MVC 概念
java
/**
* MVC 架构模式的三个核心组件：
*
* Model（模型）：
* - 负责数据和业务逻辑
* - 包括实体类、服务类、数据访问层
* - 不依赖于视图和控制器
*
* View（视图）：
* - 负责数据的展示
* - 包括 JSP、Thymeleaf、JSON、XML 等
* - 从模型获取数据并渲染给用户
*
* Controller（控制器）：
* - 负责处理用户请求
* - 协调模型和视图
* - 处理用户输入并返回响应
*/
// Model - 数据模型
@Entity
public class User {
private Long id;
private String username;
private String email;
// getters and setters
}
// View - 视图（通常是模板文件）
// user-list.html (Thymeleaf)
/*
<!DOCTYPE html>
<html xmlns:th="http://www.thymeleaf.org">
<body>
<div th:each="user : ${users}">
<span th:text="${user.username}"></span>
<span th:text="${user.email}"></span>
</div>
</body>
</html>
*/
// Controller - 控制器
@Controller
public class UserController {
@Autowired
private UserService userService;
@GetMapping("/users")
public String listUsers(Model model) {
List<User> users = userService.findAll();
model.addAttribute("users", users);
return "user-list"; // 返回视图名称
}
}2. Spring MVC 的优势
java
/**
* Spring MVC 的核心优势：
*
* 1. 松耦合：通过依赖注入实现组件间的松耦合
* 2. 灵活性：支持多种视图技术和配置方式
* 3. 可测试性：控制器易于单元测试
* 4. 可扩展性：提供丰富的扩展点
* 5. 集成性：与 Spring 生态系统无缝集成
*/
@RestController
@RequestMapping("/api/users")
public class UserRestController {
@Autowired
private UserService userService;
// 支持多种返回类型
@GetMapping
public ResponseEntity<List<User>> getUsers() {
List<User> users = userService.findAll();
return ResponseEntity.ok(users);
}
@GetMapping("/{id}")
public ResponseEntity<User> getUser(@PathVariable Long id) {
User user = userService.findById(id);
return user != null ? ResponseEntity.ok(user) : ResponseEntity.notFound().build();
}
@PostMapping
public ResponseEntity<User> createUser(@Valid @RequestBody User user) {
User savedUser = userService.save(user);
return ResponseEntity.status(HttpStatus.CREATED).body(savedUser);
}
}核心组件
1. DispatcherServlet
java
/**
* DispatcherServlet 是 Spring MVC 的前端控制器
* 负责接收所有请求并分发给相应的处理器
*/
// Web.xml 配置方式
/*
<servlet>
<servlet-name>dispatcher</servlet-name>
<servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class>
<init-param>
<param-name>contextConfigLocation</param-name>
<param-value>/WEB-INF/spring-mvc.xml</param-value>
</init-param>
<load-on-startup>1</load-on-startup>
</servlet>
<servlet-mapping>
<servlet-name>dispatcher</servlet-name>
<url-pattern>/</url-pattern>
</servlet-mapping>
*/
// Java 配置方式
@Configuration
@EnableWebMvc
@ComponentScan(basePackages = "com.example.controller")
public class WebConfig implements WebMvcConfigurer {
// 配置视图解析器
@Bean
public ThymeleafViewResolver thymeleafViewResolver() {
ThymeleafViewResolver resolver = new ThymeleafViewResolver();
resolver.setTemplateEngine(templateEngine());
resolver.setOrder(1);
resolver.setCharacterEncoding("UTF-8");
return resolver;
}
// FreeMarker 视图解析器
@Bean
public FreeMarkerConfigurer freeMarkerConfigurer() {
FreeMarkerConfigurer configurer = new FreeMarkerConfigurer();
configurer.setTemplateLoaderPath("/WEB-INF/freemarker/");
configurer.setDefaultEncoding("UTF-8");
Properties settings = new Properties();
settings.setProperty("template_update_delay", "0");
settings.setProperty("default_encoding", "UTF-8");
settings.setProperty("number_format", "0.##########");
settings.setProperty("datetime_format", "yyyy-MM-dd HH:mm:ss");
settings.setProperty("classic_compatible", "true");
configurer.setFreemarkerSettings(settings);
return configurer;
}
@Bean
public FreeMarkerViewResolver freeMarkerViewResolver() {
FreeMarkerViewResolver resolver = new FreeMarkerViewResolver();
resolver.setPrefix("");
resolver.setSuffix(".ftl");
resolver.setContentType("text/html;charset=UTF-8");
resolver.setOrder(2);
return resolver;
}
// 内容协商视图解析器
@Bean
public ContentNegotiatingViewResolver contentNegotiatingViewResolver() {
ContentNegotiatingViewResolver resolver = new ContentNegotiatingViewResolver();
// 设置内容协商管理器
ContentNegotiationManager manager = new ContentNegotiationManager(
new HeaderContentNegotiationStrategy(),
new ParameterContentNegotiationStrategy(),
new PathExtensionContentNegotiationStrategy(),
new FixedContentNegotiationStrategy(MediaType.TEXT_HTML)
);
resolver.setContentNegotiationManager(manager);
// 设置视图解析器列表
List<ViewResolver> viewResolvers = Arrays.asList(
thymeleafViewResolver(),
freeMarkerViewResolver(),
jspViewResolver()
);
resolver.setViewResolvers(viewResolvers);
// 设置默认视图
List<View> defaultViews = Arrays.asList(
new MappingJackson2JsonView(),
new MappingJackson2XmlView()
);
resolver.setDefaultViews(defaultViews);
return resolver;
}
}2. 视图控制器
java
@Controller
public class ViewController {
@Autowired
private UserService userService;
@Autowired
private ProductService productService;
// 返回视图名称
@GetMapping("/users")
public String listUsers(Model model) {
List<User> users = userService.findAll();
model.addAttribute("users", users);
model.addAttribute("title", "用户列表");
return "user/list"; // 对应 /WEB-INF/templates/user/list.html
}
// 返回 ModelAndView
@GetMapping("/users/{id}")
public ModelAndView showUser(@PathVariable Long id) {
User user = userService.findById(id);
ModelAndView mav = new ModelAndView("user/detail");
mav.addObject("user", user);
mav.addObject("title", "用户详情");
return mav;
}
// 重定向
@PostMapping("/users")
public String createUser(@Valid @ModelAttribute User user, BindingResult result) {
if (result.hasErrors()) {
return "user/form";
}
}文件上传
1. 配置文件上传
java
@Configuration
public class FileUploadConfig {
@Bean
public MultipartResolver multipartResolver() {
CommonsMultipartResolver resolver = new CommonsMultipartResolver();
resolver.setMaxUploadSize(10 * 1024 * 1024); // 10MB
resolver.setMaxInMemorySize(1024 * 1024); // 1MB
resolver.setDefaultEncoding("UTF-8");
return resolver;
}
// 或者使用 StandardServletMultipartResolver
@Bean
public MultipartResolver standardMultipartResolver() {
return new StandardServletMultipartResolver();
}
}
// application.properties 配置
/*
spring.servlet.multipart.enabled=true
spring.servlet.multipart.max-file-size=10MB
spring.servlet.multipart.max-request-size=10MB
spring.servlet.multipart.file-size-threshold=1MB
spring.servlet.multipart.location=/tmp
*/2. 文件上传控制器
java
@RestController
@RequestMapping("/api/files")
public class FileUploadController {
@Value("${file.upload.path:/tmp/uploads}")
private String uploadPath;
// 单文件上传
@PostMapping("/upload")
public ResponseEntity<FileUploadResponse> uploadFile(
@RequestParam("file") MultipartFile file,
@RequestParam(value = "description", required = false) String description) {
try {
// 验证文件
validateFile(file);
// 生成文件名
String fileName = generateFileName(file.getOriginalFilename());
// 确保上传目录存在
Path uploadDir = Paths.get(uploadPath);
if (!Files.exists(uploadDir)) {
Files.createDirectories(uploadDir);
}
// 保存文件
Path filePath = uploadDir.resolve(fileName);
Files.copy(file.getInputStream(), filePath, StandardCopyOption.REPLACE_EXISTING);
// 构建响应
FileUploadResponse response = FileUploadResponse.builder()
.fileName(fileName)
.originalFileName(file.getOriginalFilename())
.fileSize(file.getSize())
.contentType(file.getContentType())
.description(description)
.uploadTime(LocalDateTime.now())
.downloadUrl("/api/files/download/" + fileName)
.build();
return ResponseEntity.ok(response);
} catch (IOException e) {
throw new FileUploadException("文件上传失败", e);
}
}
// 多文件上传
@PostMapping("/upload/multiple")
public ResponseEntity<List<FileUploadResponse>> uploadMultipleFiles(
@RequestParam("files") MultipartFile[] files) {
List<FileUploadResponse> responses = new ArrayList<>();
for (MultipartFile file : files) {
try {
validateFile(file);
String fileName = generateFileName(file.getOriginalFilename());
Path filePath = Paths.get(uploadPath).resolve(fileName);
Files.copy(file.getInputStream(), filePath, StandardCopyOption.REPLACE_EXISTING);
FileUploadResponse response = FileUploadResponse.builder()
.fileName(fileName)
.originalFileName(file.getOriginalFilename())
.fileSize(file.getSize())
.contentType(file.getContentType())
.uploadTime(LocalDateTime.now())
.downloadUrl("/api/files/download/" + fileName)
.build();
responses.add(response);
} catch (IOException e) {
// 记录错误但继续处理其他文件
log.error("文件上传失败: {}", file.getOriginalFilename(), e);
}
}
return ResponseEntity.ok(responses);
}
// 文件下载
@GetMapping("/download/{fileName}")
public ResponseEntity<Resource> downloadFile(@PathVariable String fileName) {
try {
Path filePath = Paths.get(uploadPath).resolve(fileName);
Resource resource = new UrlResource(filePath.toUri());
if (!resource.exists() || !resource.isReadable()) {
throw new FileNotFoundException("文件不存在: " + fileName);
}
// 获取文件的 MIME 类型
String contentType = Files.probeContentType(filePath);
if (contentType == null) {
contentType = "application/octet-stream";
}
return ResponseEntity.ok()
.contentType(MediaType.parseMediaType(contentType))
.header(HttpHeaders.CONTENT_DISPOSITION,
"attachment; filename=\"" + resource.getFilename() + "\"")
.body(resource);
} catch (IOException e) {
throw new FileDownloadException("文件下载失败", e);
}
}
// 图片预览
@GetMapping("/preview/{fileName}")
public ResponseEntity<Resource> previewImage(@PathVariable String fileName) {
try {
Path filePath = Paths.get(uploadPath).resolve(fileName);
Resource resource = new UrlResource(filePath.toUri());
if (!resource.exists() || !resource.isReadable()) {
throw new FileNotFoundException("文件不存在: " + fileName);
}
String contentType = Files.probeContentType(filePath);
if (contentType == null || !contentType.startsWith("image/")) {
throw new IllegalArgumentException("不是有效的图片文件");
}
return ResponseEntity.ok()
.contentType(MediaType.parseMediaType(contentType))
.body(resource);
} catch (IOException e) {
throw new FileDownloadException("图片预览失败", e);
}
}
// 文件删除
@DeleteMapping("/delete/{fileName}")
public ResponseEntity<Void> deleteFile(@PathVariable String fileName) {
try {
Path filePath = Paths.get(uploadPath).resolve(fileName);
if (Files.exists(filePath)) {
Files.delete(filePath);
}
return ResponseEntity.noContent().build();
} catch (IOException e) {
throw new FileDeleteException("文件删除失败", e);
}
}
private void validateFile(MultipartFile file) {
if (file.isEmpty()) {
throw new IllegalArgumentException("文件不能为空");
}
// 检查文件大小
if (file.getSize() > 10 * 1024 * 1024) { // 10MB
throw new IllegalArgumentException("文件大小不能超过10MB");
}
// 检查文件类型
String contentType = file.getContentType();
if (contentType == null) {
throw new IllegalArgumentException("无法确定文件类型");
}
List<String> allowedTypes = Arrays.asList(
"image/jpeg", "image/png", "image/gif", "image/webp",
"application/pdf", "text/plain", "application/msword",
"application/vnd.openxmlformats-officedocument.wordprocessingml.document"
);
if (!allowedTypes.contains(contentType)) {
throw new IllegalArgumentException("不支持的文件类型: " + contentType);
}
// 检查文件扩展名
String fileName = file.getOriginalFilename();
if (fileName != null) {
String extension = fileName.substring(fileName.lastIndexOf(".") + 1).toLowerCase();
List<String> allowedExtensions = Arrays.asList(
"jpg", "jpeg", "png", "gif", "webp", "pdf", "txt", "doc", "docx"
);
if (!allowedExtensions.contains(extension)) {
throw new IllegalArgumentException("不支持的文件扩展名: " + extension);
}
}
}
private String generateFileName(String originalFileName) {
String extension = "";
if (originalFileName != null && originalFileName.contains(".")) {
extension = originalFileName.substring(originalFileName.lastIndexOf("."));
}
return UUID.randomUUID().toString() + extension;
}
}
// 文件上传响应类
@Data
@Builder
public class FileUploadResponse {
private String fileName;
private String originalFileName;
private long fileSize;
private String contentType;
private String description;
private LocalDateTime uploadTime;
private String downloadUrl;
}
// 自定义异常
public class FileUploadException extends RuntimeException {
public FileUploadException(String message, Throwable cause) {
super(message, cause);
}
}
public class FileDownloadException extends RuntimeException {
public FileDownloadException(String message, Throwable cause) {
super(message, cause);
}
}
public class FileDeleteException extends RuntimeException {
public FileDeleteException(String message, Throwable cause) {
super(message, cause);
}
}3. 表单文件上传
java
@Controller
@RequestMapping("/upload")
public class FileUploadFormController {
@GetMapping
public String uploadForm() {
return "upload/form";
}
@PostMapping
public String handleFileUpload(
@RequestParam("file") MultipartFile file,
@RequestParam("description") String description,
RedirectAttributes redirectAttributes) {
try {
if (file.isEmpty()) {
redirectAttributes.addFlashAttribute("error", "请选择要上传的文件");
return "redirect:/upload";
}
// 处理文件上传逻辑
String fileName = saveFile(file);
redirectAttributes.addFlashAttribute("success",
"文件上传成功: " + file.getOriginalFilename());
redirectAttributes.addFlashAttribute("fileName", fileName);
return "redirect:/upload/success";
} catch (Exception e) {
redirectAttributes.addFlashAttribute("error", "文件上传失败: " + e.getMessage());
return "redirect:/upload";
}
}
@GetMapping("/success")
public String uploadSuccess() {
return "upload/success";
}
private String saveFile(MultipartFile file) throws IOException {
// 实现文件保存逻辑
return "saved-file-name";
}
}国际化
1. 国际化配置
java
@Configuration
public class InternationalizationConfig implements WebMvcConfigurer {
// 消息源配置
@Bean
public MessageSource messageSource() {
ResourceBundleMessageSource messageSource = new ResourceBundleMessageSource();
messageSource.setBasenames("messages/messages", "messages/validation");
messageSource.setDefaultEncoding("UTF-8");
messageSource.setCacheSeconds(3600);
messageSource.setFallbackToSystemLocale(false);
return messageSource;
}
// 区域解析器
@Bean
public LocaleResolver localeResolver() {
SessionLocaleResolver resolver = new SessionLocaleResolver();
resolver.setDefaultLocale(Locale.SIMPLIFIED_CHINESE);
return resolver;
}
// 或者使用 Cookie 区域解析器
@Bean
public LocaleResolver cookieLocaleResolver() {
CookieLocaleResolver resolver = new CookieLocaleResolver();
resolver.setDefaultLocale(Locale.SIMPLIFIED_CHINESE);
resolver.setCookieName("language");
resolver.setCookieMaxAge(3600 * 24 * 30); // 30天
return resolver;
}
// 或者使用 Accept-Language 头解析器
@Bean
public LocaleResolver acceptHeaderLocaleResolver() {
AcceptHeaderLocaleResolver resolver = new AcceptHeaderLocaleResolver();
resolver.setDefaultLocale(Locale.SIMPLIFIED_CHINESE);
resolver.setSupportedLocales(Arrays.asList(
Locale.SIMPLIFIED_CHINESE,
Locale.US,
Locale.JAPAN
));
return resolver;
}
// 区域变更拦截器
@Bean
public LocaleChangeInterceptor localeChangeInterceptor() {
LocaleChangeInterceptor interceptor = new LocaleChangeInterceptor();
interceptor.setParamName("lang");
return interceptor;
}
@Override
public void addInterceptors(InterceptorRegistry registry) {
registry.addInterceptor(localeChangeInterceptor());
}
}2. 消息资源文件
properties
# messages/messages_zh_CN.properties
welcome.message=欢迎使用我们的系统
user.name=用户名
user.email=邮箱
user.age=年龄
button.submit=提交
button.cancel=取消
button.save=保存
button.delete=删除
button.edit=编辑
error.required={0}不能为空
error.email.invalid=邮箱格式不正确
error.age.range=年龄必须在{0}到{1}之间
success.user.created=用户创建成功
success.user.updated=用户更新成功
success.user.deleted=用户删除成功
# messages/messages_en_US.properties
welcome.message=Welcome to our system
user.name=Username
user.email=Email
user.age=Age
button.submit=Submit
button.cancel=Cancel
button.save=Save
button.delete=Delete
button.edit=Edit
error.required={0} is required
error.email.invalid=Invalid email format
error.age.range=Age must be between {0} and {1}
success.user.created=User created successfully
success.user.updated=User updated successfully
success.user.deleted=User deleted successfully
# messages/messages_ja_JP.properties
welcome.message=私たちのシステムへようこそ
user.name=ユーザー名
user.email=メール
user.age=年齢
button.submit=送信
button.cancel=キャンセル
button.save=保存
button.delete=削除
button.edit=編集
error.required={0}は必須です
error.email.invalid=メール形式が正しくありません
error.age.range=年齢は{0}から{1}の間である必要があります
success.user.created=ユーザーが正常に作成されました
success.user.updated=ユーザーが正常に更新されました
success.user.deleted=ユーザーが正常に削除されました3. 国际化控制器
java
@Controller
public class InternationalizationController {
@Autowired
private MessageSource messageSource;
@GetMapping("/")
public String home(Model model, Locale locale) {
String welcomeMessage = messageSource.getMessage("welcome.message", null, locale);
model.addAttribute("welcomeMessage", welcomeMessage);
return "home";
}
@GetMapping("/users/new")
public String newUserForm(Model model, Locale locale) {
model.addAttribute("user", new User());
// 添加本地化标签
model.addAttribute("userNameLabel",
messageSource.getMessage("user.name", null, locale));
model.addAttribute("userEmailLabel",
messageSource.getMessage("user.email", null, locale));
model.addAttribute("userAgeLabel",
messageSource.getMessage("user.age", null, locale));
model.addAttribute("submitButton",
messageSource.getMessage("button.submit", null, locale));
return "user/form";
}
@PostMapping("/users")
public String createUser(@Valid @ModelAttribute User user,
BindingResult result,
RedirectAttributes redirectAttributes,
Locale locale) {
if (result.hasErrors()) {
return "user/form";
}
userService.save(user);
String successMessage = messageSource.getMessage(
"success.user.created", null, locale);
redirectAttributes.addFlashAttribute("successMessage", successMessage);
return "redirect:/users";
}
// 切换语言
@GetMapping("/change-language")
public String changeLanguage(@RequestParam("lang") String language,
HttpServletRequest request) {
String referer = request.getHeader("Referer");
if (referer != null && !referer.isEmpty()) {
return "redirect:" + referer + "?lang=" + language;
}
return "redirect:/?lang=" + language;
}
}
// 国际化工具类
@Component
public class MessageHelper {
@Autowired
private MessageSource messageSource;
public String getMessage(String code, Locale locale) {
return messageSource.getMessage(code, null, locale);
}
public String getMessage(String code, Object[] args, Locale locale) {
return messageSource.getMessage(code, args, locale);
}
public String getMessage(String code, Object[] args, String defaultMessage, Locale locale) {
return messageSource.getMessage(code, args, defaultMessage, locale);
}
}
// REST API 国际化
@RestController
@RequestMapping("/api/messages")
public class MessageController {
@Autowired
private MessageHelper messageHelper;
@GetMapping("/welcome")
public ResponseEntity<Map<String, String>> getWelcomeMessage(Locale locale) {
Map<String, String> response = new HashMap<>();
response.put("message", messageHelper.getMessage("welcome.message", locale));
response.put("locale", locale.toString());
return ResponseEntity.ok(response);
}
@GetMapping("/validation-error")
public ResponseEntity<Map<String, String>> getValidationError(
@RequestParam String field,
Locale locale) {
String fieldName = messageHelper.getMessage("user." + field, locale);
String errorMessage = messageHelper.getMessage(
"error.required", new Object[]{fieldName}, locale);
Map<String, String> response = new HashMap<>();
response.put("field", field);
response.put("message", errorMessage);
return ResponseEntity.ok(response);
}
}4. 模板中的国际化
html
<!-- Thymeleaf 模板 -->
<!DOCTYPE html>
<html xmlns:th="http://www.thymeleaf.org">
<head>
<title th:text="#{page.title}">Title</title>
<meta charset="UTF-8">
</head>
<body>
<h1 th:text="#{welcome.message}">Welcome</h1>
<!-- 语言切换 -->
<div class="language-switcher">
<a th:href="@{''(lang=zh_CN)}" th:text="#{language.chinese}">中文</a>
<a th:href="@{''(lang=en_US)}" th:text="#{language.english}">English</a>
<a th:href="@{''(lang=ja_JP)}" th:text="#{language.japanese}">日本語</a>
</div>
<!-- 表单 -->
<form th:action="@{/users}" th:object="${user}" method="post">
<div>
<label th:text="#{user.name}">Name:</label>
<input type="text" th:field="*{name}" th:placeholder="#{user.name.placeholder}">
<span th:if="${#fields.hasErrors('name')}"
th:errors="*{name}"
class="error"></span>
</div>
<div>
<label th:text="#{user.email}">Email:</label>
<input type="email" th:field="*{email}" th:placeholder="#{user.email.placeholder}">
<span th:if="${#fields.hasErrors('email')}"
th:errors="*{email}"
class="error"></span>
</div>
<div>
<label th:text="#{user.age}">Age:</label>
<input type="number" th:field="*{age}" th:placeholder="#{user.age.placeholder}">
<span th:if="${#fields.hasErrors('age')}"
th:errors="*{age}"
class="error"></span>
</div>
<button type="submit" th:text="#{button.submit}">Submit</button>
<a th:href="@{/users}" th:text="#{button.cancel}">Cancel</a>
</form>
<!-- 消息显示 -->
<div th:if="${successMessage}" class="alert alert-success">
<span th:text="${successMessage}"></span>
</div>
<!-- 使用参数的消息 -->
<p th:text="#{user.info(${user.name}, ${user.age})}">User info</p>
<!-- 条件消息 -->
<p th:text="${user.age >= 18} ? #{user.adult} : #{user.minor}">Age status</p>
</body>
</html>静态资源处理
1. 静态资源配置
java
@Configuration
public class StaticResourceConfig implements WebMvcConfigurer {
@Override
public void addResourceHandlers(ResourceHandlerRegistry registry) {
// 静态资源映射
registry.addResourceHandler("/static/**")
.addResourceLocations("classpath:/static/")
.setCacheControl(CacheControl.maxAge(Duration.ofDays(30)));
// 图片资源
registry.addResourceHandler("/images/**")
.addResourceLocations("classpath:/static/images/", "file:/opt/uploads/images/")
.setCacheControl(CacheControl.maxAge(Duration.ofDays(7)));
// CSS 和 JS 资源
registry.addResourceHandler("/css/**")
.addResourceLocations("classpath:/static/css/")
.setCacheControl(CacheControl.maxAge(Duration.ofDays(30))
.cachePublic()
.mustRevalidate());
registry.addResourceHandler("/js/**")
.addResourceLocations("classpath:/static/js/")
.setCacheControl(CacheControl.maxAge(Duration.ofDays(30)));
// 文件下载
registry.addResourceHandler("/downloads/**")
.addResourceLocations("file:/opt/downloads/")
.setCacheControl(CacheControl.noCache());
// WebJars 支持
registry.addResourceHandler("/webjars/**")
.addResourceLocations("classpath:/META-INF/resources/webjars/")
.setCacheControl(CacheControl.maxAge(Duration.ofDays(365)));
}
// 默认 Servlet 处理器
@Override
public void configureDefaultServletHandling(DefaultServletHandlerConfigurer configurer) {
configurer.enable();
}
// 资源版本策略
@Override
public void addResourceHandlers(ResourceHandlerRegistry registry) {
registry.addResourceHandler("/resources/**")
.addResourceLocations("/public/", "classpath:/static/")
.setCacheControl(CacheControl.maxAge(Duration.ofDays(365)))
.resourceChain(true)
.addResolver(new VersionResourceResolver()
.addContentVersionStrategy("/**"))
.addTransformer(new CssLinkResourceTransformer());
}
}2. 资源控制器
java
@Controller
public class ResourceController {
@Value("${app.upload.path:/opt/uploads}")
private String uploadPath;
// 动态图片服务
@GetMapping("/images/{category}/{filename:.+}")
public ResponseEntity<Resource> getImage(
@PathVariable String category,
@PathVariable String filename,
HttpServletRequest request) throws IOException {
// 安全检查
if (filename.contains("..") || category.contains("..")) {
return ResponseEntity.badRequest().build();
}
Path imagePath = Paths.get(uploadPath, category, filename);
Resource resource = new UrlResource(imagePath.toUri());
if (!resource.exists() || !resource.isReadable()) {
return ResponseEntity.notFound().build();
}
// 确定内容类型
String contentType = Files.probeContentType(imagePath);
if (contentType == null) {
contentType = "application/octet-stream";
}
// 设置缓存头
return ResponseEntity.ok()
.contentType(MediaType.parseMediaType(contentType))
.cacheControl(CacheControl.maxAge(Duration.ofDays(7)))
.body(resource);
}
// 缩略图服务
@GetMapping("/thumbnails/{filename:.+}")
public ResponseEntity<Resource> getThumbnail(
@PathVariable String filename,
@RequestParam(defaultValue = "200") int width,
@RequestParam(defaultValue = "200") int height) throws IOException {
Path originalPath = Paths.get(uploadPath, "images", filename);
if (!Files.exists(originalPath)) {
return ResponseEntity.notFound().build();
}
// 生成缩略图缓存路径
String thumbnailName = String.format("%s_%dx%d_%s",
FilenameUtils.getBaseName(filename), width, height,
FilenameUtils.getExtension(filename));
Path thumbnailPath = Paths.get(uploadPath, "thumbnails", thumbnailName);
// 如果缩略图不存在，生成它
if (!Files.exists(thumbnailPath)) {
generateThumbnail(originalPath, thumbnailPath, width, height);
}
Resource resource = new UrlResource(thumbnailPath.toUri());
return ResponseEntity.ok()
.contentType(MediaType.IMAGE_JPEG)
.cacheControl(CacheControl.maxAge(Duration.ofDays(30)))
.body(resource);
}
private void generateThumbnail(Path originalPath, Path thumbnailPath, int width, int height)
throws IOException {
// 确保缩略图目录存在
Files.createDirectories(thumbnailPath.getParent());
// 使用 Java 2D API 生成缩略图
BufferedImage originalImage = ImageIO.read(originalPath.toFile());
// 计算缩放比例
double scaleX = (double) width / originalImage.getWidth();
double scaleY = (double) height / originalImage.getHeight();
double scale = Math.min(scaleX, scaleY);
int scaledWidth = (int) (originalImage.getWidth() * scale);
int scaledHeight = (int) (originalImage.getHeight() * scale);
// 创建缩略图
BufferedImage thumbnailImage = new BufferedImage(scaledWidth, scaledHeight, BufferedImage.TYPE_INT_RGB);
Graphics2D g2d = thumbnailImage.createGraphics();
g2d.setRenderingHint(RenderingHints.KEY_INTERPOLATION, RenderingHints.VALUE_INTERPOLATION_BILINEAR);
g2d.drawImage(originalImage, 0, 0, scaledWidth, scaledHeight, null);
g2d.dispose();
// 保存缩略图
ImageIO.write(thumbnailImage, "jpg", thumbnailPath.toFile());
}
}3. 资源压缩和优化
java
@Configuration
public class ResourceOptimizationConfig implements WebMvcConfigurer {
@Override
public void addResourceHandlers(ResourceHandlerRegistry registry) {
// 启用资源链和压缩
registry.addResourceHandler("/assets/**")
.addResourceLocations("classpath:/static/")
.setCacheControl(CacheControl.maxAge(Duration.ofDays(365)))
.resourceChain(true)
.addResolver(new GzipResourceResolver())
.addResolver(new PathResourceResolver())
.addTransformer(new CssLinkResourceTransformer())
.addTransformer(new AppCacheManifestTransformer());
}
// 自定义 Gzip 资源解析器
public static class GzipResourceResolver implements ResourceResolver {
@Override
public Resource resolveResource(HttpServletRequest request, String requestPath,
List<? extends Resource> locations, ResourceResolverChain chain) {
Resource resource = chain.resolveResource(request, requestPath, locations);
if (resource == null) {
return null;
}
// 检查是否支持 Gzip
String acceptEncoding = request.getHeader("Accept-Encoding");
if (acceptEncoding != null && acceptEncoding.contains("gzip")) {
// 查找 .gz 版本
try {
Resource gzipResource = resource.createRelative(resource.getFilename() + ".gz");
if (gzipResource.exists()) {
return new GzipResource(gzipResource);
}
} catch (IOException e) {
// 忽略错误，返回原始资源
}
}
return resource;
}
@Override
public String resolveUrlPath(String resourcePath, List<? extends Resource> locations,
ResourceResolverChain chain) {
return chain.resolveUrlPath(resourcePath, locations);
}
}
// Gzip 资源包装器
public static class GzipResource implements Resource {
private final Resource resource;
public GzipResource(Resource resource) {
this.resource = resource;
}
@Override
public InputStream getInputStream() throws IOException {
return new GZIPInputStream(resource.getInputStream());
}
@Override
public boolean exists() {
return resource.exists();
}
@Override
public URL getURL() throws IOException {
return resource.getURL();
}
@Override
public URI getURI() throws IOException {
return resource.getURI();
}
@Override
public File getFile() throws IOException {
return resource.getFile();
}
@Override
public long contentLength() throws IOException {
return resource.contentLength();
}
@Override
public long lastModified() throws IOException {
return resource.lastModified();
}
@Override
public Resource createRelative(String relativePath) throws IOException {
return resource.createRelative(relativePath);
}
@Override
public String getFilename() {
String filename = resource.getFilename();
return filename != null && filename.endsWith(".gz")
? filename.substring(0, filename.length() - 3)
: filename;
}
@Override
public String getDescription() {
return resource.getDescription();
}
}
}最佳实践与总结
1. 架构设计原则
java
// 1. 分层架构
@RestController
@RequestMapping("/api/users")
public class UserController {
@Autowired
private UserService userService; // 业务层
@Autowired
private UserMapper userMapper; // 数据转换
@GetMapping
public ResponseEntity<List<UserDTO>> getAllUsers() {
List<User> users = userService.findAll();
List<UserDTO> userDTOs = users.stream()
.map(userMapper::toDTO)
.collect(Collectors.toList());
return ResponseEntity.ok(userDTOs);
}
}
// 2. 统一响应格式
@Data
@Builder
public class ApiResponse<T> {
private boolean success;
private String message;
private T data;
private String timestamp;
private String path;
public static <T> ApiResponse<T> success(T data) {
return ApiResponse.<T>builder()
.success(true)
.data(data)
.timestamp(LocalDateTime.now().toString())
.build();
}
public static <T> ApiResponse<T> error(String message) {
return ApiResponse.<T>builder()
.success(false)
.message(message)
.timestamp(LocalDateTime.now().toString())
.build();
}
}
// 3. 统一异常处理
@ControllerAdvice
public class GlobalExceptionHandler {
@ExceptionHandler(ValidationException.class)
public ResponseEntity<ApiResponse<Void>> handleValidation(ValidationException ex) {
return ResponseEntity.badRequest()
.body(ApiResponse.error(ex.getMessage()));
}
@ExceptionHandler(EntityNotFoundException.class)
public ResponseEntity<ApiResponse<Void>> handleNotFound(EntityNotFoundException ex) {
return ResponseEntity.notFound()
.build();
}
}2. 性能优化
java
// 1. 缓存配置
@Configuration
@EnableCaching
public class CacheConfig {
@Bean
public CacheManager cacheManager() {
CaffeineCacheManager cacheManager = new CaffeineCacheManager();
cacheManager.setCaffeine(Caffeine.newBuilder()
.maximumSize(1000)
.expireAfterWrite(Duration.ofMinutes(10))
.recordStats());
return cacheManager;
}
}
// 2. 异步处理
@Configuration
@EnableAsync
public class AsyncConfig implements AsyncConfigurer {
@Override
public Executor getAsyncExecutor() {
ThreadPoolTaskExecutor executor = new ThreadPoolTaskExecutor();
executor.setCorePoolSize(5);
executor.setMaxPoolSize(20);
executor.setQueueCapacity(100);
executor.setThreadNamePrefix("async-");
executor.initialize();
return executor;
}
}
// 3. 数据库连接池
@Configuration
public class DataSourceConfig {
@Bean
@Primary
public DataSource dataSource() {
HikariConfig config = new HikariConfig();
config.setJdbcUrl("jdbc:mysql://localhost:3306/mydb");
config.setUsername("user");
config.setPassword("password");
config.setMaximumPoolSize(20);
config.setMinimumIdle(5);
config.setConnectionTimeout(30000);
config.setIdleTimeout(600000);
config.setMaxLifetime(1800000);
return new HikariDataSource(config);
}
}3. 安全最佳实践
java
// 1. 输入验证
@RestController
public class SecureController {
@PostMapping("/users")
public ResponseEntity<User> createUser(
@Valid @RequestBody CreateUserRequest request) {
// 额外的业务验证
if (userService.existsByEmail(request.getEmail())) {
throw new DuplicateEmailException("邮箱已存在");
}
User user = userService.create(request);
return ResponseEntity.status(HttpStatus.CREATED).body(user);
}
}
// 2. SQL 注入防护
@Repository
public class UserRepository {
@Autowired
private JdbcTemplate jdbcTemplate;
public List<User> findByName(String name) {
// 使用参数化查询
String sql = "SELECT * FROM users WHERE name = ?";
return jdbcTemplate.query(sql, new Object[]{name}, new UserRowMapper());
}
}
// 3. XSS 防护
@Component
public class XssFilter implements Filter {
@Override
public void doFilter(ServletRequest request, ServletResponse response,
FilterChain chain) throws IOException, ServletException {
XssHttpServletRequestWrapper wrappedRequest =
new XssHttpServletRequestWrapper((HttpServletRequest) request);
chain.doFilter(wrappedRequest, response);
}
}4. 测试策略
java
// 1. 单元测试
@ExtendWith(MockitoExtension.class)
class UserControllerTest {
@Mock
private UserService userService;
@InjectMocks
private UserController userController;
@Test
void shouldReturnAllUsers() {
// Given
List<User> users = Arrays.asList(new User("John"), new User("Jane"));
when(userService.findAll()).thenReturn(users);
// When
ResponseEntity<List<UserDTO>> response = userController.getAllUsers();
// Then
assertThat(response.getStatusCode()).isEqualTo(HttpStatus.OK);
assertThat(response.getBody()).hasSize(2);
}
}
// 2. 集成测试
@SpringBootTest(webEnvironment = SpringBootTest.WebEnvironment.RANDOM_PORT)
@AutoConfigureTestDatabase(replace = AutoConfigureTestDatabase.Replace.NONE)
class UserControllerIntegrationTest {
@Autowired
private TestRestTemplate restTemplate;
@Test
void shouldCreateUser() {
// Given
CreateUserRequest request = new CreateUserRequest("John", "john@example.com");
// When
ResponseEntity<User> response = restTemplate.postForEntity(
"/api/users", request, User.class);
// Then
assertThat(response.getStatusCode()).isEqualTo(HttpStatus.CREATED);
assertThat(response.getBody().getName()).isEqualTo("John");
}
}
// 3. Web 层测试
@WebMvcTest(UserController.class)
class UserControllerWebTest {
@Autowired
private MockMvc mockMvc;
@MockBean
private UserService userService;
@Test
void shouldReturnUsers() throws Exception {
// Given
List<User> users = Arrays.asList(new User("John"));
when(userService.findAll()).thenReturn(users);
// When & Then
mockMvc.perform(get("/api/users"))
.andExpect(status().isOk())
.andExpect(jsonPath("$", hasSize(1)))
.andExpect(jsonPath("$[0].name", is("John")));
}
}5. 监控和日志
java
// 1. 日志配置
@Slf4j
@RestController
public class MonitoredController {
@GetMapping("/api/users/{id}")
public ResponseEntity<User> getUser(@PathVariable Long id) {
log.info("获取用户信息，ID: {}", id);
try {
User user = userService.findById(id);
log.info("成功获取用户信息: {}", user.getName());
return ResponseEntity.ok(user);
} catch (EntityNotFoundException e) {
log.warn("用户不存在，ID: {}", id);
throw e;
} catch (Exception e) {
log.error("获取用户信息失败，ID: {}", id, e);
throw new InternalServerException("系统错误");
}
}
}
// 2. 性能监控
@Component
@Aspect
public class PerformanceMonitoringAspect {
@Around("@annotation(Monitored)")
public Object monitor(ProceedingJoinPoint joinPoint) throws Throwable {
long startTime = System.currentTimeMillis();
try {
Object result = joinPoint.proceed();
long duration = System.currentTimeMillis() - startTime;
log.info("方法 {} 执行耗时: {}ms",
joinPoint.getSignature().getName(), duration);
return result;
} catch (Exception e) {
long duration = System.currentTimeMillis() - startTime;
log.error("方法 {} 执行失败，耗时: {}ms",
joinPoint.getSignature().getName(), duration, e);
throw e;
}
}
}
@Target(ElementType.METHOD)
@Retention(RetentionPolicy.RUNTIME)
public @interface Monitored {
}总结
Spring MVC 是一个功能强大、灵活且易于使用的 Web 框架，它提供了：
- 清晰的架构：基于 MVC 模式的分层架构
- 灵活的配置：支持注解和 Java 配置
- 强大的功能：请求映射、数据绑定、验证、视图解析等
- 良好的扩展性：拦截器、异常处理、自定义组件
- 完善的生态：与 Spring 生态系统无缝集成
通过合理使用 Spring MVC 的各种特性，可以构建出高质量、可维护的 Web 应用程序。关键是要遵循最佳实践，注重代码质量和性能优化。
userService.save(user);
return "redirect:/users"; // 重定向到用户列表
}
// 转发
@GetMapping("/admin/users")
public String adminUsers() {
return "forward:/users"; // 转发到 /users
}
// 条件视图
@GetMapping("/dashboard")
public String dashboard(HttpServletRequest request, Model model) {
String userAgent = request.getHeader("User-Agent");
if (userAgent != null && userAgent.toLowerCase().contains("mobile")) {
model.addAttribute("layout", "mobile");
return "dashboard/mobile";
} else {
model.addAttribute("layout", "desktop");
return "dashboard/desktop";
}
}
}
### 3. 自定义视图
```java
// 自定义 JSON 视图
public class CustomJsonView extends AbstractView {
public CustomJsonView() {
setContentType(MediaType.APPLICATION_JSON_VALUE);
}
@Override
protected void renderMergedOutputModel(Map<String, Object> model,
HttpServletRequest request,
HttpServletResponse response) throws Exception {
response.setContentType(getContentType());
response.setCharacterEncoding("UTF-8");
ObjectMapper mapper = new ObjectMapper();
mapper.configure(SerializationFeature.INDENT_OUTPUT, true);
// 自定义 JSON 格式
Map<String, Object> result = new HashMap<>();
result.put("success", true);
result.put("timestamp", System.currentTimeMillis());
result.put("data", model);
String json = mapper.writeValueAsString(result);
response.getWriter().write(json);
}
}
// 自定义 Excel 视图
public class ExcelView extends AbstractView {
public ExcelView() {
setContentType("application/vnd.ms-excel");
}
@Override
protected void renderMergedOutputModel(Map<String, Object> model,
HttpServletRequest request,
HttpServletResponse response) throws Exception {
response.setContentType(getContentType());
response.setHeader("Content-Disposition", "attachment; filename=export.xlsx");
@SuppressWarnings("unchecked")
List<User> users = (List<User>) model.get("users");
Workbook workbook = new XSSFWorkbook();
Sheet sheet = workbook.createSheet("用户数据");
// 创建标题行
Row headerRow = sheet.createRow(0);
headerRow.createCell(0).setCellValue("ID");
headerRow.createCell(1).setCellValue("用户名");
headerRow.createCell(2).setCellValue("邮箱");
headerRow.createCell(3).setCellValue("年龄");
// 填充数据
for (int i = 0; i < users.size(); i++) {
User user = users.get(i);
Row row = sheet.createRow(i + 1);
row.createCell(0).setCellValue(user.getId());
row.createCell(1).setCellValue(user.getUsername());
row.createCell(2).setCellValue(user.getEmail());
row.createCell(3).setCellValue(user.getAge());
}
workbook.write(response.getOutputStream());
workbook.close();
}
}
// 注册自定义视图
@Configuration
public class CustomViewConfig {
@Bean
public BeanNameViewResolver beanNameViewResolver() {
BeanNameViewResolver resolver = new BeanNameViewResolver();
resolver.setOrder(0); // 最高优先级
return resolver;
}
@Bean("customJson")
public View customJsonView() {
return new CustomJsonView();
}
@Bean("excel")
public View excelView() {
return new ExcelView();
}
}
// 使用自定义视图
@Controller
public class ExportController {
@GetMapping("/export/users.json")
public String exportUsersJson(Model model) {
List<User> users = userService.findAll();
model.addAttribute("users", users);
return "customJson"; // 使用自定义 JSON 视图
}
@GetMapping("/export/users.xlsx")
public String exportUsersExcel(Model model) {
List<User> users = userService.findAll();
model.addAttribute("users", users);
return "excel"; // 使用自定义 Excel 视图
}
}异常处理
1. 全局异常处理
java
@ControllerAdvice
@Slf4j
public class GlobalExceptionHandler {
// 处理业务异常
@ExceptionHandler(BusinessException.class)
public ResponseEntity<ErrorResponse> handleBusinessException(BusinessException ex) {
log.warn("业务异常：{}", ex.getMessage());
ErrorResponse error = ErrorResponse.builder()
.code(ex.getCode())
.message(ex.getMessage())
.timestamp(LocalDateTime.now())
.build();
return ResponseEntity.status(HttpStatus.BAD_REQUEST).body(error);
}
// 处理资源未找到异常
@ExceptionHandler(EntityNotFoundException.class)
public ResponseEntity<ErrorResponse> handleEntityNotFound(EntityNotFoundException ex) {
log.warn("资源未找到：{}", ex.getMessage());
ErrorResponse error = ErrorResponse.builder()
.code("ENTITY_NOT_FOUND")
.message(ex.getMessage())
.timestamp(LocalDateTime.now())
.build();
return ResponseEntity.status(HttpStatus.NOT_FOUND).body(error);
}
// 处理访问拒绝异常
@ExceptionHandler(AccessDeniedException.class)
public ResponseEntity<ErrorResponse> handleAccessDenied(AccessDeniedException ex) {
log.warn("访问被拒绝：{}", ex.getMessage());
ErrorResponse error = ErrorResponse.builder()
.code("ACCESS_DENIED")
.message("您没有权限访问此资源")
.timestamp(LocalDateTime.now())
.build();
return ResponseEntity.status(HttpStatus.FORBIDDEN).body(error);
}
// 处理系统异常
@ExceptionHandler(Exception.class)
public ResponseEntity<ErrorResponse> handleGenericException(Exception ex, HttpServletRequest request) {
log.error("系统异常，请求URL：{}", request.getRequestURL(), ex);
ErrorResponse error = ErrorResponse.builder()
.code("INTERNAL_ERROR")
.message("系统内部错误，请稍后重试")
.timestamp(LocalDateTime.now())
.path(request.getRequestURI())
.build();
return ResponseEntity.status(HttpStatus.INTERNAL_SERVER_ERROR).body(error);
}
// 处理 HTTP 方法不支持异常
@ExceptionHandler(HttpRequestMethodNotSupportedException.class)
public ResponseEntity<ErrorResponse> handleMethodNotSupported(HttpRequestMethodNotSupportedException ex) {
log.warn("不支持的HTTP方法：{}", ex.getMethod());
ErrorResponse error = ErrorResponse.builder()
.code("METHOD_NOT_SUPPORTED")
.message(String.format("不支持的HTTP方法：%s", ex.getMethod()))
.timestamp(LocalDateTime.now())
.build();
return ResponseEntity.status(HttpStatus.METHOD_NOT_ALLOWED).body(error);
}
// 处理媒体类型不支持异常
@ExceptionHandler(HttpMediaTypeNotSupportedException.class)
public ResponseEntity<ErrorResponse> handleMediaTypeNotSupported(HttpMediaTypeNotSupportedException ex) {
log.warn("不支持的媒体类型：{}", ex.getContentType());
ErrorResponse error = ErrorResponse.builder()
.code("MEDIA_TYPE_NOT_SUPPORTED")
.message(String.format("不支持的媒体类型：%s", ex.getContentType()))
.timestamp(LocalDateTime.now())
.build();
return ResponseEntity.status(HttpStatus.UNSUPPORTED_MEDIA_TYPE).body(error);
}
}
// 错误响应类
@Data
@Builder
public class ErrorResponse {
private String code;
private String message;
private LocalDateTime timestamp;
private String path;
private Map<String, Object> details;
public static ErrorResponseBuilder builder() {
return new ErrorResponseBuilder();
}
}
// 自定义业务异常
public class BusinessException extends RuntimeException {
private final String code;
public BusinessException(String code, String message) {
super(message);
this.code = code;
}
public BusinessException(String code, String message, Throwable cause) {
super(message, cause);
this.code = code;
}
public String getCode() {
return code;
}
}2. 特定异常处理
java
// 用户相关异常处理
@ControllerAdvice(assignableTypes = {UserController.class})
public class UserExceptionHandler {
@ExceptionHandler(UserNotFoundException.class)
public ResponseEntity<ErrorResponse> handleUserNotFound(UserNotFoundException ex) {
ErrorResponse error = ErrorResponse.builder()
.code("USER_NOT_FOUND")
.message(ex.getMessage())
.timestamp(LocalDateTime.now())
.build();
return ResponseEntity.status(HttpStatus.NOT_FOUND).body(error);
}
@ExceptionHandler(DuplicateUsernameException.class)
public ResponseEntity<ErrorResponse> handleDuplicateUsername(DuplicateUsernameException ex) {
ErrorResponse error = ErrorResponse.builder()
.code("DUPLICATE_USERNAME")
.message("用户名已存在")
.timestamp(LocalDateTime.now())
.build();
return ResponseEntity.status(HttpStatus.CONFLICT).body(error);
}
}
// 文件上传异常处理
@ControllerAdvice
public class FileUploadExceptionHandler {
@ExceptionHandler(MaxUploadSizeExceededException.class)
public ResponseEntity<ErrorResponse> handleMaxUploadSizeExceeded(MaxUploadSizeExceededException ex) {
ErrorResponse error = ErrorResponse.builder()
.code("FILE_SIZE_EXCEEDED")
.message("上传文件大小超过限制")
.timestamp(LocalDateTime.now())
.build();
return ResponseEntity.status(HttpStatus.PAYLOAD_TOO_LARGE).body(error);
}
@ExceptionHandler(MultipartException.class)
public ResponseEntity<ErrorResponse> handleMultipartException(MultipartException ex) {
ErrorResponse error = ErrorResponse.builder()
.code("MULTIPART_ERROR")
.message("文件上传格式错误")
.timestamp(LocalDateTime.now())
.build();
return ResponseEntity.status(HttpStatus.BAD_REQUEST).body(error);
}
}3. 异常处理配置
java
@Configuration
public class ExceptionHandlingConfig {
// 配置简单异常解析器
@Bean
public SimpleMappingExceptionResolver simpleMappingExceptionResolver() {
SimpleMappingExceptionResolver resolver = new SimpleMappingExceptionResolver();
Properties mappings = new Properties();
mappings.setProperty("BusinessException", "error/business");
mappings.setProperty("EntityNotFoundException", "error/not-found");
mappings.setProperty("AccessDeniedException", "error/access-denied");
mappings.setProperty("Exception", "error/general");
resolver.setExceptionMappings(mappings);
resolver.setDefaultErrorView("error/default");
resolver.setExceptionAttribute("exception");
return resolver;
}
// 配置默认异常属性
@Bean
public DefaultHandlerExceptionResolver defaultHandlerExceptionResolver() {
return new DefaultHandlerExceptionResolver();
}
}拦截器
1. 自定义拦截器
java
// 日志拦截器
@Slf4j
public class LoggingInterceptor implements HandlerInterceptor {
private static final String START_TIME = "startTime";
@Override
public boolean preHandle(HttpServletRequest request,
HttpServletResponse response,
Object handler) throws Exception {
long startTime = System.currentTimeMillis();
request.setAttribute(START_TIME, startTime);
String method = request.getMethod();
String uri = request.getRequestURI();
String queryString = request.getQueryString();
String userAgent = request.getHeader("User-Agent");
String clientIp = getClientIpAddress(request);
log.info("请求开始 - {} {} {} - IP: {} - User-Agent: {}",
method, uri, queryString != null ? "?" + queryString : "",
clientIp, userAgent);
return true;
}
@Override
public void postHandle(HttpServletRequest request,
HttpServletResponse response,
Object handler,
ModelAndView modelAndView) throws Exception {
if (modelAndView != null) {
log.debug("视图名称：{}", modelAndView.getViewName());
log.debug("模型数据：{}", modelAndView.getModel().keySet());
}
}
@Override
public void afterCompletion(HttpServletRequest request,
HttpServletResponse response,
Object handler,
Exception ex) throws Exception {
Long startTime = (Long) request.getAttribute(START_TIME);
if (startTime != null) {
long endTime = System.currentTimeMillis();
long duration = endTime - startTime;
String method = request.getMethod();
String uri = request.getRequestURI();
int status = response.getStatus();
if (ex != null) {
log.error("请求异常 - {} {} - 状态码: {} - 耗时: {}ms - 异常: {}",
method, uri, status, duration, ex.getMessage());
} else {
log.info("请求完成 - {} {} - 状态码: {} - 耗时: {}ms",
method, uri, status, duration);
}
}
}
private String getClientIpAddress(HttpServletRequest request) {
String xForwardedFor = request.getHeader("X-Forwarded-For");
if (xForwardedFor != null && !xForwardedFor.isEmpty() && !"unknown".equalsIgnoreCase(xForwardedFor)) {
return xForwardedFor.split(",")[0].trim();
}
String xRealIp = request.getHeader("X-Real-IP");
if (xRealIp != null && !xRealIp.isEmpty() && !"unknown".equalsIgnoreCase(xRealIp)) {
return xRealIp;
}
return request.getRemoteAddr();
}
}
// 认证拦截器
@Component
public class AuthenticationInterceptor implements HandlerInterceptor {
@Autowired
private JwtTokenService jwtTokenService;
@Override
public boolean preHandle(HttpServletRequest request,
HttpServletResponse response,
Object handler) throws Exception {
// 检查是否需要认证
if (handler instanceof HandlerMethod) {
HandlerMethod handlerMethod = (HandlerMethod) handler;
// 检查方法或类上是否有 @PublicApi 注解
if (handlerMethod.hasMethodAnnotation(PublicApi.class) ||
handlerMethod.getBeanType().isAnnotationPresent(PublicApi.class)) {
return true; // 公开API，无需认证
}
}
// 获取 token
String token = extractToken(request);
if (token == null) {
response.setStatus(HttpStatus.UNAUTHORIZED.value());
response.getWriter().write("{\"error\":\"Missing authentication token\"}");
return false;
}
// 验证 token
try {
User user = jwtTokenService.validateToken(token);
request.setAttribute("currentUser", user);
return true;
} catch (Exception e) {
response.setStatus(HttpStatus.UNAUTHORIZED.value());
response.getWriter().write("{\"error\":\"Invalid authentication token\"}");
return false;
}
}
private String extractToken(HttpServletRequest request) {
String authHeader = request.getHeader("Authorization");
if (authHeader != null && authHeader.startsWith("Bearer ")) {
return authHeader.substring(7);
}
return null;
}
}
// 权限拦截器
@Component
public class AuthorizationInterceptor implements HandlerInterceptor {
@Override
public boolean preHandle(HttpServletRequest request,
HttpServletResponse response,
Object handler) throws Exception {
if (handler instanceof HandlerMethod) {
HandlerMethod handlerMethod = (HandlerMethod) handler;
// 检查是否需要特定权限
RequirePermission requirePermission = handlerMethod.getMethodAnnotation(RequirePermission.class);
if (requirePermission == null) {
requirePermission = handlerMethod.getBeanType().getAnnotation(RequirePermission.class);
}
if (requirePermission != null) {
User currentUser = (User) request.getAttribute("currentUser");
if (currentUser == null) {
response.setStatus(HttpStatus.UNAUTHORIZED.value());
return false;
}
String[] requiredPermissions = requirePermission.value();
if (!hasPermissions(currentUser, requiredPermissions)) {
response.setStatus(HttpStatus.FORBIDDEN.value());
response.getWriter().write("{\"error\":\"Insufficient permissions\"}");
return false;
}
}
}
return true;
}
private boolean hasPermissions(User user, String[] requiredPermissions) {
Set<String> userPermissions = user.getPermissions();
return Arrays.stream(requiredPermissions)
.allMatch(userPermissions::contains);
}
}2. 拦截器配置
java
@Configuration
public class InterceptorConfig implements WebMvcConfigurer {
@Autowired
private AuthenticationInterceptor authenticationInterceptor;
@Autowired
private AuthorizationInterceptor authorizationInterceptor;
@Override
public void addInterceptors(InterceptorRegistry registry) {
// 日志拦截器 - 拦截所有请求
registry.addInterceptor(new LoggingInterceptor())
.addPathPatterns("/**")
.excludePathPatterns("/static/**", "/css/**", "/js/**", "/images/**");
// 认证拦截器 - 拦截 API 请求
registry.addInterceptor(authenticationInterceptor)
.addPathPatterns("/api/**")
.excludePathPatterns("/api/public/**", "/api/auth/**");
// 权限拦截器 - 在认证拦截器之后
registry.addInterceptor(authorizationInterceptor)
.addPathPatterns("/api/**")
.excludePathPatterns("/api/public/**", "/api/auth/**");
// 限流拦截器
registry.addInterceptor(new RateLimitInterceptor())
.addPathPatterns("/api/**");
// 国际化拦截器
registry.addInterceptor(new LocaleChangeInterceptor())
.addPathPatterns("/**");
}
}
// 限流拦截器
@Component
public class RateLimitInterceptor implements HandlerInterceptor {
private final Map<String, RateLimiter> rateLimiters = new ConcurrentHashMap<>();
@Override
public boolean preHandle(HttpServletRequest request,
HttpServletResponse response,
Object handler) throws Exception {
String clientIp = getClientIpAddress(request);
RateLimiter rateLimiter = rateLimiters.computeIfAbsent(clientIp,
k -> RateLimiter.create(10.0)); // 每秒10个请求
if (!rateLimiter.tryAcquire()) {
response.setStatus(HttpStatus.TOO_MANY_REQUESTS.value());
response.getWriter().write("{\"error\":\"Rate limit exceeded\"}");
return false;
}
return true;
}
private String getClientIpAddress(HttpServletRequest request) {
// 实现获取客户端IP的逻辑
return request.getRemoteAddr();
}
}3. 拦截器注解
java
// 公开API注解
@Target({ElementType.METHOD, ElementType.TYPE})
@Retention(RetentionPolicy.RUNTIME)
public @interface PublicApi {
}
// 权限要求注解
@Target({ElementType.METHOD, ElementType.TYPE})
@Retention(RetentionPolicy.RUNTIME)
public @interface RequirePermission {
String[] value();
}
// 限流注解
@Target({ElementType.METHOD, ElementType.TYPE})
@Retention(RetentionPolicy.RUNTIME)
public @interface RateLimit {
double value() default 10.0; // 每秒请求数
TimeUnit timeUnit() default TimeUnit.SECONDS;
}
// 使用示例
@RestController
@RequestMapping("/api/users")
public class UserController {
@GetMapping
@PublicApi
public List<User> getAllUsers() {
return userService.findAll();
}
@PostMapping
@RequirePermission({"USER_CREATE"})
public ResponseEntity<User> createUser(@Valid @RequestBody User user) {
User savedUser = userService.save(user);
return ResponseEntity.status(HttpStatus.CREATED).body(savedUser);
}
@DeleteMapping("/{id}")
@RequirePermission({"USER_DELETE", "ADMIN"})
@RateLimit(5.0)
public ResponseEntity<Void> deleteUser(@PathVariable Long id) {
userService.delete(id);
return ResponseEntity.noContent().build();
}
}
``` ViewResolver viewResolver() {
InternalResourceViewResolver resolver = new InternalResourceViewResolver();
resolver.setPrefix("/WEB-INF/views/");
resolver.setSuffix(".jsp");
return resolver;
}
// 配置静态资源处理
@Override
public void addResourceHandlers(ResourceHandlerRegistry registry) {
registry.addResourceHandler("/static/**")
.addResourceLocations("/static/");
}
}
// Spring Boot 自动配置
@SpringBootApplication
public class Application {
public static void main(String[] args) {
SpringApplication.run(Application.class, args);
}
}2. HandlerMapping
java
/**
* HandlerMapping 负责将请求映射到处理器
*/
@Controller
public class ProductController {
// 简单路径映射
@RequestMapping("/products")
public String listProducts() {
return "product-list";
}
// 带参数的路径映射
@RequestMapping("/products/{id}")
public String showProduct(@PathVariable Long id, Model model) {
// 处理逻辑
return "product-detail";
}
// HTTP 方法映射
@RequestMapping(value = "/products", method = RequestMethod.POST)
public String createProduct(@ModelAttribute Product product) {
// 创建产品
return "redirect:/products";
}
}
// 使用专门的注解
@RestController
@RequestMapping("/api/products")
public class ProductRestController {
@GetMapping
public List<Product> getAllProducts() {
return productService.findAll();
}
@GetMapping("/{id}")
public Product getProduct(@PathVariable Long id) {
return productService.findById(id);
}
@PostMapping
public Product createProduct(@RequestBody Product product) {
return productService.save(product);
}
@PutMapping("/{id}")
public Product updateProduct(@PathVariable Long id, @RequestBody Product product) {
product.setId(id);
return productService.update(product);
}
@DeleteMapping("/{id}")
public ResponseEntity<Void> deleteProduct(@PathVariable Long id) {
productService.delete(id);
return ResponseEntity.noContent().build();
}
}3. HandlerAdapter
java
/**
* HandlerAdapter 负责调用处理器方法
* Spring MVC 提供了多种 HandlerAdapter
*/
// 注解驱动的处理器适配器配置
@Configuration
@EnableWebMvc
public class WebMvcConfig implements WebMvcConfigurer {
// 配置消息转换器
@Override
public void configureMessageConverters(List<HttpMessageConverter<?>> converters) {
// JSON 转换器
MappingJackson2HttpMessageConverter jsonConverter = new MappingJackson2HttpMessageConverter();
jsonConverter.setObjectMapper(new ObjectMapper());
converters.add(jsonConverter);
// XML 转换器
MappingJackson2XmlHttpMessageConverter xmlConverter = new MappingJackson2XmlHttpMessageConverter();
converters.add(xmlConverter);
}
// 配置参数解析器
@Override
public void addArgumentResolvers(List<HandlerMethodArgumentResolver> resolvers) {
resolvers.add(new CustomArgumentResolver());
}
// 配置返回值处理器
@Override
public void addReturnValueHandlers(List<HandlerMethodReturnValueHandler> handlers) {
handlers.add(new CustomReturnValueHandler());
}
}
// 自定义参数解析器
public class CustomArgumentResolver implements HandlerMethodArgumentResolver {
@Override
public boolean supportsParameter(MethodParameter parameter) {
return parameter.hasParameterAnnotation(CurrentUser.class);
}
@Override
public Object resolveArgument(MethodParameter parameter,
ModelAndViewContainer mavContainer,
NativeWebRequest webRequest,
WebDataBinderFactory binderFactory) throws Exception {
// 从 session 或 security context 中获取当前用户
return getCurrentUser(webRequest);
}
private User getCurrentUser(NativeWebRequest request) {
// 实现获取当前用户的逻辑
return new User();
}
}4. ViewResolver
java
/**
* ViewResolver 负责解析视图名称到具体的视图实现
*/
@Configuration
public class ViewConfig {
// JSP 视图解析器
@Bean
public ViewResolver jspViewResolver() {
InternalResourceViewResolver resolver = new InternalResourceViewResolver();
resolver.setPrefix("/WEB-INF/views/");
resolver.setSuffix(".jsp");
resolver.setOrder(2);
return resolver;
}
// Thymeleaf 视图解析器
@Bean
public SpringTemplateEngine templateEngine() {
SpringTemplateEngine engine = new SpringTemplateEngine();
engine.setTemplateResolver(templateResolver());
return engine;
}
@Bean
public ITemplateResolver templateResolver() {
SpringResourceTemplateResolver resolver = new SpringResourceTemplateResolver();
resolver.setPrefix("/WEB-INF/templates/");
resolver.setSuffix(".html");
resolver.setTemplateMode(TemplateMode.HTML);
return resolver;
}
@Bean
public ThymeleafViewResolver thymeleafViewResolver() {
ThymeleafViewResolver resolver = new ThymeleafViewResolver();
resolver.setTemplateEngine(templateEngine());
resolver.setOrder(1);
return resolver;
}
// 内容协商视图解析器
@Bean
public ContentNegotiatingViewResolver contentNegotiatingViewResolver() {
ContentNegotiatingViewResolver resolver = new ContentNegotiatingViewResolver();
List<ViewResolver> viewResolvers = new ArrayList<>();
viewResolvers.add(thymeleafViewResolver());
viewResolvers.add(jspViewResolver());
resolver.setViewResolvers(viewResolvers);
List<View> defaultViews = new ArrayList<>();
defaultViews.add(new MappingJackson2JsonView());
resolver.setDefaultViews(defaultViews);
return resolver;
}
}请求处理流程
1. 完整的请求处理流程
java
/**
* Spring MVC 请求处理流程：
*
* 1. 客户端发送请求到 DispatcherServlet
* 2. DispatcherServlet 查询 HandlerMapping 找到处理器
* 3. DispatcherServlet 调用 HandlerAdapter 执行处理器
* 4. 处理器执行业务逻辑并返回 ModelAndView
* 5. DispatcherServlet 将 ModelAndView 传给 ViewResolver
* 6. ViewResolver 解析视图名称并返回 View
* 7. DispatcherServlet 渲染视图
* 8. 返回响应给客户端
*/
@Controller
public class OrderController {
@Autowired
private OrderService orderService;
// 1. 接收请求
@GetMapping("/orders/{id}")
public ModelAndView showOrder(@PathVariable Long id) {
// 2. 执行业务逻辑
Order order = orderService.findById(id);
// 3. 准备模型数据
ModelAndView mav = new ModelAndView();
mav.addObject("order", order);
mav.addObject("orderItems", order.getItems());
// 4. 设置视图名称
mav.setViewName("order-detail");
return mav; // 5. 返回 ModelAndView
}
// 使用 Model 参数的简化方式
@GetMapping("/orders")
public String listOrders(Model model,
@RequestParam(defaultValue = "0") int page,
@RequestParam(defaultValue = "10") int size) {
Page<Order> orders = orderService.findAll(PageRequest.of(page, size));
model.addAttribute("orders", orders.getContent());
model.addAttribute("currentPage", page);
model.addAttribute("totalPages", orders.getTotalPages());
return "order-list";
}
}2. 异步请求处理
java
@RestController
@RequestMapping("/api/async")
public class AsyncController {
@Autowired
private AsyncService asyncService;
// 返回 Callable
@GetMapping("/callable")
public Callable<String> handleCallable() {
return () -> {
Thread.sleep(2000); // 模拟长时间处理
return "Callable result";
};
}
// 返回 DeferredResult
@GetMapping("/deferred")
public DeferredResult<String> handleDeferred() {
DeferredResult<String> deferredResult = new DeferredResult<>(5000L);
// 异步处理
CompletableFuture.supplyAsync(() -> {
try {
Thread.sleep(2000);
return "Deferred result";
} catch (InterruptedException e) {
throw new RuntimeException(e);
}
}).whenComplete((result, throwable) -> {
if (throwable != null) {
deferredResult.setErrorResult(throwable);
} else {
deferredResult.setResult(result);
}
});
return deferredResult;
}
// 使用 @Async 注解
@GetMapping("/future")
public CompletableFuture<String> handleFuture() {
return asyncService.processAsync();
}
// Server-Sent Events
@GetMapping(value = "/events", produces = MediaType.TEXT_EVENT_STREAM_VALUE)
public SseEmitter handleSse() {
SseEmitter emitter = new SseEmitter();
// 异步发送事件
CompletableFuture.runAsync(() -> {
try {
for (int i = 0; i < 10; i++) {
emitter.send("Event " + i);
Thread.sleep(1000);
}
emitter.complete();
} catch (Exception e) {
emitter.completeWithError(e);
}
});
return emitter;
}
}
@Service
public class AsyncService {
@Async
public CompletableFuture<String> processAsync() {
try {
Thread.sleep(2000);
return CompletableFuture.completedFuture("Async processing completed");
} catch (InterruptedException e) {
return CompletableFuture.failedFuture(e);
}
}
}控制器开发
1. 控制器基础
java
// 传统控制器
@Controller
public class TraditionalController {
@RequestMapping("/hello")
public ModelAndView hello() {
ModelAndView mav = new ModelAndView("hello");
mav.addObject("message", "Hello World!");
return mav;
}
}
// RESTful 控制器
@RestController
@RequestMapping("/api/books")
public class BookController {
@Autowired
private BookService bookService;
@GetMapping
public List<Book> getAllBooks() {
return bookService.findAll();
}
@GetMapping("/{id}")
public ResponseEntity<Book> getBook(@PathVariable Long id) {
Book book = bookService.findById(id);
return book != null ? ResponseEntity.ok(book) : ResponseEntity.notFound().build();
}
@PostMapping
public ResponseEntity<Book> createBook(@Valid @RequestBody Book book) {
Book savedBook = bookService.save(book);
URI location = ServletUriComponentsBuilder
.fromCurrentRequest()
.path("/{id}")
.buildAndExpand(savedBook.getId())
.toUri();
return ResponseEntity.created(location).body(savedBook);
}
@PutMapping("/{id}")
public ResponseEntity<Book> updateBook(@PathVariable Long id, @Valid @RequestBody Book book) {
if (!bookService.existsById(id)) {
return ResponseEntity.notFound().build();
}
book.setId(id);
Book updatedBook = bookService.save(book);
return ResponseEntity.ok(updatedBook);
}
@DeleteMapping("/{id}")
public ResponseEntity<Void> deleteBook(@PathVariable Long id) {
if (!bookService.existsById(id)) {
return ResponseEntity.notFound().build();
}
bookService.deleteById(id);
return ResponseEntity.noContent().build();
}
}2. 控制器继承和组合
java
// 基础控制器
@RestController
public abstract class BaseController<T, ID> {
protected abstract BaseService<T, ID> getService();
@GetMapping
public ResponseEntity<List<T>> findAll() {
List<T> entities = getService().findAll();
return ResponseEntity.ok(entities);
}
@GetMapping("/{id}")
public ResponseEntity<T> findById(@PathVariable ID id) {
Optional<T> entity = getService().findById(id);
return entity.map(ResponseEntity::ok)
.orElse(ResponseEntity.notFound().build());
}
@PostMapping
public ResponseEntity<T> create(@Valid @RequestBody T entity) {
T savedEntity = getService().save(entity);
return ResponseEntity.status(HttpStatus.CREATED).body(savedEntity);
}
@PutMapping("/{id}")
public ResponseEntity<T> update(@PathVariable ID id, @Valid @RequestBody T entity) {
if (!getService().existsById(id)) {
return ResponseEntity.notFound().build();
}
T updatedEntity = getService().save(entity);
return ResponseEntity.ok(updatedEntity);
}
@DeleteMapping("/{id}")
public ResponseEntity<Void> delete(@PathVariable ID id) {
if (!getService().existsById(id)) {
return ResponseEntity.notFound().build();
}
getService().deleteById(id);
return ResponseEntity.noContent().build();
}
}
// 具体控制器
@RestController
@RequestMapping("/api/users")
public class UserController extends BaseController<User, Long> {
@Autowired
private UserService userService;
@Override
protected BaseService<User, Long> getService() {
return userService;
}
// 特定的业务方法
@PostMapping("/{id}/activate")
public ResponseEntity<Void> activateUser(@PathVariable Long id) {
userService.activateUser(id);
return ResponseEntity.ok().build();
}
@PostMapping("/{id}/deactivate")
public ResponseEntity<Void> deactivateUser(@PathVariable Long id) {
userService.deactivateUser(id);
return ResponseEntity.ok().build();
}
@GetMapping("/search")
public ResponseEntity<List<User>> searchUsers(@RequestParam String keyword) {
List<User> users = userService.searchByKeyword(keyword);
return ResponseEntity.ok(users);
}
}3. 控制器建议
java
// 全局控制器建议
@ControllerAdvice
public class GlobalControllerAdvice {
// 全局异常处理
@ExceptionHandler(EntityNotFoundException.class)
public ResponseEntity<ErrorResponse> handleEntityNotFound(EntityNotFoundException ex) {
ErrorResponse error = new ErrorResponse("ENTITY_NOT_FOUND", ex.getMessage());
return ResponseEntity.status(HttpStatus.NOT_FOUND).body(error);
}
@ExceptionHandler(ValidationException.class)
public ResponseEntity<ErrorResponse> handleValidation(ValidationException ex) {
ErrorResponse error = new ErrorResponse("VALIDATION_ERROR", ex.getMessage());
return ResponseEntity.status(HttpStatus.BAD_REQUEST).body(error);
}
// 全局数据绑定
@ModelAttribute("currentUser")
public User getCurrentUser(HttpServletRequest request) {
// 从 session 或 security context 获取当前用户
return getCurrentUserFromSession(request);
}
// 全局数据绑定初始化
@InitBinder
public void initBinder(WebDataBinder binder) {
// 自定义日期格式
SimpleDateFormat dateFormat = new SimpleDateFormat("yyyy-MM-dd");
binder.registerCustomEditor(Date.class, new CustomDateEditor(dateFormat, false));
// 字符串去空格
binder.registerCustomEditor(String.class, new StringTrimmerEditor(true));
}
}
// 特定控制器建议
@ControllerAdvice(assignableTypes = {UserController.class, AdminController.class})
public class UserControllerAdvice {
@ExceptionHandler(UserNotFoundException.class)
public ResponseEntity<ErrorResponse> handleUserNotFound(UserNotFoundException ex) {
ErrorResponse error = new ErrorResponse("USER_NOT_FOUND", ex.getMessage());
return ResponseEntity.status(HttpStatus.NOT_FOUND).body(error);
}
@ModelAttribute("userRoles")
public List<Role> getUserRoles() {
return roleService.findAll();
}
}请求映射
1. 基本映射
java
@Controller
@RequestMapping("/products")
public class ProductController {
// 简单路径映射
@RequestMapping("/list")
public String listProducts() {
return "product-list";
}
// HTTP 方法限制
@RequestMapping(value = "/create", method = RequestMethod.GET)
public String showCreateForm() {
return "product-form";
}
@RequestMapping(value = "/create", method = RequestMethod.POST)
public String createProduct(@ModelAttribute Product product) {
// 处理创建逻辑
return "redirect:/products/list";
}
// 使用组合注解
@GetMapping("/edit/{id}")
public String showEditForm(@PathVariable Long id, Model model) {
Product product = productService.findById(id);
model.addAttribute("product", product);
return "product-form";
}
@PostMapping("/edit/{id}")
public String updateProduct(@PathVariable Long id, @ModelAttribute Product product) {
product.setId(id);
productService.update(product);
return "redirect:/products/list";
}
@DeleteMapping("/delete/{id}")
@ResponseBody
public ResponseEntity<Void> deleteProduct(@PathVariable Long id) {
productService.delete(id);
return ResponseEntity.ok().build();
}
}2. 高级映射
java
@RestController
@RequestMapping("/api/v1")
public class AdvancedMappingController {
// 路径变量
@GetMapping("/users/{userId}/orders/{orderId}")
public Order getUserOrder(@PathVariable Long userId, @PathVariable Long orderId) {
return orderService.findByUserIdAndOrderId(userId, orderId);
}
// 正则表达式路径变量
@GetMapping("/files/{filename:.+}")
public ResponseEntity<Resource> downloadFile(@PathVariable String filename) {
Resource file = fileService.loadFile(filename);
return ResponseEntity.ok()
.header(HttpHeaders.CONTENT_DISPOSITION, "attachment; filename=\"" + filename + "\"")
.body(file);
}
// 矩阵变量
@GetMapping("/cars/{brand};color={color};year={year}")
public List<Car> findCars(@PathVariable String brand,
@MatrixVariable String color,
@MatrixVariable int year) {
return carService.findByBrandAndColorAndYear(brand, color, year);
}
// 请求参数
@GetMapping("/search")
public List<Product> searchProducts(
@RequestParam String keyword,
@RequestParam(defaultValue = "0") int page,
@RequestParam(defaultValue = "10") int size,
@RequestParam(required = false) String category) {
return productService.search(keyword, category, page, size);
}
// 请求头
@GetMapping("/info")
public ResponseEntity<String> getInfo(
@RequestHeader("User-Agent") String userAgent,
@RequestHeader(value = "Accept-Language", defaultValue = "en") String language) {
return ResponseEntity.ok("User-Agent: " + userAgent + ", Language: " + language);
}
// Cookie
@GetMapping("/preferences")
public UserPreferences getPreferences(@CookieValue("theme") String theme) {
return userPreferenceService.getByTheme(theme);
}
// 内容类型限制
@PostMapping(value = "/upload", consumes = MediaType.MULTIPART_FORM_DATA_VALUE)
public ResponseEntity<String> uploadFile(@RequestParam("file") MultipartFile file) {
// 处理文件上传
return ResponseEntity.ok("File uploaded successfully");
}
// 响应类型限制
@GetMapping(value = "/data", produces = {MediaType.APPLICATION_JSON_VALUE, MediaType.APPLICATION_XML_VALUE})
public Data getData() {
return dataService.getData();
}
}3. 条件映射
java
@RestController
public class ConditionalMappingController {
// 基于请求参数的条件映射
@GetMapping(value = "/api/data", params = "version=1")
public DataV1 getDataV1() {
return new DataV1();
}
@GetMapping(value = "/api/data", params = "version=2")
public DataV2 getDataV2() {
return new DataV2();
}
// 基于请求头的条件映射
@GetMapping(value = "/api/content", headers = "X-API-Version=1")
public ContentV1 getContentV1() {
return new ContentV1();
}
@GetMapping(value = "/api/content", headers = "X-API-Version=2")
public ContentV2 getContentV2() {
return new ContentV2();
}
// 基于媒体类型的条件映射
@PostMapping(value = "/api/process", consumes = MediaType.APPLICATION_JSON_VALUE)
public ResponseEntity<String> processJson(@RequestBody JsonData data) {
return ResponseEntity.ok("Processed JSON data");
}
@PostMapping(value = "/api/process", consumes = MediaType.APPLICATION_XML_VALUE)
public ResponseEntity<String> processXml(@RequestBody XmlData data) {
return ResponseEntity.ok("Processed XML data");
}
// 自定义条件
@GetMapping("/api/mobile")
@ConditionalOnMobile
public MobileResponse getMobileData() {
return new MobileResponse();
}
@GetMapping("/api/desktop")
@ConditionalOnDesktop
public DesktopResponse getDesktopData() {
return new DesktopResponse();
}
}
// 自定义条件注解
@Target({ElementType.METHOD, ElementType.TYPE})
@Retention(RetentionPolicy.RUNTIME)
@RequestMapping
public @interface ConditionalOnMobile {
}
// 自定义条件处理器
@Component
public class MobileCondition implements RequestCondition<MobileCondition> {
@Override
public MobileCondition combine(MobileCondition other) {
return this;
}
@Override
public MobileCondition getMatchingCondition(HttpServletRequest request) {
String userAgent = request.getHeader("User-Agent");
if (userAgent != null && userAgent.toLowerCase().contains("mobile")) {
return this;
}
return null;
}
@Override
public int compareTo(MobileCondition other, HttpServletRequest request) {
return 0;
}
}参数绑定
1. 基本参数绑定
java
@RestController
@RequestMapping("/api/binding")
public class ParameterBindingController {
// 基本类型参数
@GetMapping("/basic")
public String basicTypes(
@RequestParam String name,
@RequestParam int age,
@RequestParam boolean active,
@RequestParam(required = false) Double salary) {
return String.format("Name: %s, Age: %d, Active: %b, Salary: %s",
name, age, active, salary);
}
// 数组和集合参数
@GetMapping("/collections")
public String collections(
@RequestParam String[] tags,
@RequestParam List<String> categories,
@RequestParam Set<Integer> ids) {
return String.format("Tags: %s, Categories: %s, IDs: %s",
Arrays.toString(tags), categories, ids);
}
// 日期参数
@GetMapping("/dates")
public String dates(
@RequestParam @DateTimeFormat(pattern = "yyyy-MM-dd") Date startDate,
@RequestParam @DateTimeFormat(iso = DateTimeFormat.ISO.DATE_TIME) LocalDateTime endDateTime) {
return String.format("Start: %s, End: %s", startDate, endDateTime);
}
// 枚举参数
@GetMapping("/enum")
public String enumParam(@RequestParam Status status) {
return "Status: " + status;
}
// 对象参数绑定
@PostMapping("/object")
public ResponseEntity<User> createUser(@Valid @RequestBody User user) {
User savedUser = userService.save(user);
return ResponseEntity.status(HttpStatus.CREATED).body(savedUser);
}
// 表单参数绑定
@PostMapping("/form")
public String handleForm(@ModelAttribute UserForm userForm, BindingResult result) {
if (result.hasErrors()) {
return "user-form";
}
userService.save(userForm.toUser());
return "redirect:/users";
}
}
// 用户表单类
public class UserForm {
@NotBlank(message = "用户名不能为空")
@Size(min = 3, max = 20, message = "用户名长度必须在3-20之间")
private String username;
@Email(message = "邮箱格式不正确")
private String email;
@Min(value = 18, message = "年龄不能小于18")
@Max(value = 100, message = "年龄不能大于100")
private Integer age;
@DateTimeFormat(pattern = "yyyy-MM-dd")
private Date birthDate;
private List<String> hobbies;
// getters and setters
public User toUser() {
User user = new User();
user.setUsername(username);
user.setEmail(email);
user.setAge(age);
user.setBirthDate(birthDate);
user.setHobbies(hobbies);
return user;
}
}2. 自定义参数绑定
java
// 自定义参数解析器
public class CustomUserArgumentResolver implements HandlerMethodArgumentResolver {
@Override
public boolean supportsParameter(MethodParameter parameter) {
return parameter.hasParameterAnnotation(CurrentUser.class) &&
parameter.getParameterType().equals(User.class);
}
@Override
public Object resolveArgument(MethodParameter parameter,
ModelAndViewContainer mavContainer,
NativeWebRequest webRequest,
WebDataBinderFactory binderFactory) throws Exception {
HttpServletRequest request = webRequest.getNativeRequest(HttpServletRequest.class);
// 从 session 获取用户
HttpSession session = request.getSession(false);
if (session != null) {
User user = (User) session.getAttribute("currentUser");
if (user != null) {
return user;
}
}
// 从 JWT token 获取用户
String token = request.getHeader("Authorization");
if (token != null && token.startsWith("Bearer ")) {
String jwt = token.substring(7);
return jwtService.getUserFromToken(jwt);
}
throw new IllegalArgumentException("无法获取当前用户");
}
}
// 自定义注解
@Target(ElementType.PARAMETER)
@Retention(RetentionPolicy.RUNTIME)
public @interface CurrentUser {
}
// 注册自定义解析器
@Configuration
public class WebMvcConfig implements WebMvcConfigurer {
@Override
public void addArgumentResolvers(List<HandlerMethodArgumentResolver> resolvers) {
resolvers.add(new CustomUserArgumentResolver());
}
}
// 使用自定义参数解析器
@RestController
@RequestMapping("/api/profile")
public class ProfileController {
@GetMapping
public ResponseEntity<User> getProfile(@CurrentUser User currentUser) {
return ResponseEntity.ok(currentUser);
}
@PutMapping
public ResponseEntity<User> updateProfile(@CurrentUser User currentUser,
@Valid @RequestBody UserUpdateRequest request) {
// 更新用户信息
currentUser.setEmail(request.getEmail());
currentUser.setPhone(request.getPhone());
User updatedUser = userService.update(currentUser);
return ResponseEntity.ok(updatedUser);
}
}3. 数据绑定配置
java
@Configuration
public class DataBindingConfig {
// 全局数据绑定配置
@InitBinder
public void initBinder(WebDataBinder binder) {
// 日期格式化
SimpleDateFormat dateFormat = new SimpleDateFormat("yyyy-MM-dd HH:mm:ss");
dateFormat.setLenient(false);
binder.registerCustomEditor(Date.class, new CustomDateEditor(dateFormat, true));
// 字符串处理
binder.registerCustomEditor(String.class, new StringTrimmerEditor(true));
// 数字格式化
NumberFormat numberFormat = NumberFormat.getInstance();
binder.registerCustomEditor(Double.class, new CustomNumberEditor(Double.class, numberFormat, true));
// 禁止绑定某些字段（安全考虑）
binder.setDisallowedFields("id", "createdAt", "updatedAt");
// 必需字段
binder.setRequiredFields("username", "email");
}
// 自定义属性编辑器
@Bean
public PropertyEditorRegistrar customPropertyEditorRegistrar() {
return registry -> {
registry.registerCustomEditor(Status.class, new StatusPropertyEditor());
registry.registerCustomEditor(Priority.class, new PriorityPropertyEditor());
};
}
}
// 自定义属性编辑器
public class StatusPropertyEditor extends PropertyEditorSupport {
@Override
public void setAsText(String text) throws IllegalArgumentException {
if (StringUtils.hasText(text)) {
setValue(Status.valueOf(text.toUpperCase()));
} else {
setValue(null);
}
}
@Override
public String getAsText() {
Status status = (Status) getValue();
return status != null ? status.name() : "";
}
}
// 自定义转换器
@Component
public class StringToUserConverter implements Converter<String, User> {
@Autowired
private UserService userService;
@Override
public User convert(String source) {
if (StringUtils.hasText(source)) {
try {
Long userId = Long.parseLong(source);
return userService.findById(userId);
} catch (NumberFormatException e) {
// 可能是用户名
return userService.findByUsername(source);
}
}
return null;
}
}
// 注册转换器
@Configuration
public class ConversionConfig implements WebMvcConfigurer {
@Autowired
private StringToUserConverter stringToUserConverter;
@Override
public void addFormatters(FormatterRegistry registry) {
registry.addConverter(stringToUserConverter);
// 添加格式化器
registry.addFormatter(new DateFormatter("yyyy-MM-dd"));
registry.addFormatter(new NumberStyleFormatter("#,##0.00"));
}
}数据验证
1. Bean Validation
java
// 实体类验证
public class User {
@NotNull(message = "ID不能为空")
private Long id;
@NotBlank(message = "用户名不能为空")
@Size(min = 3, max = 20, message = "用户名长度必须在3-20之间")
@Pattern(regexp = "^[a-zA-Z0-9_]+$", message = "用户名只能包含字母、数字和下划线")
private String username;
@NotBlank(message = "邮箱不能为空")
@Email(message = "邮箱格式不正确")
private String email;
@NotNull(message = "年龄不能为空")
@Min(value = 18, message = "年龄不能小于18")
@Max(value = 100, message = "年龄不能大于100")
private Integer age;
@Past(message = "出生日期必须是过去的日期")
@DateTimeFormat(pattern = "yyyy-MM-dd")
private Date birthDate;
@DecimalMin(value = "0.0", message = "薪资不能为负数")
@DecimalMax(value = "999999.99", message = "薪资不能超过999999.99")
@Digits(integer = 6, fraction = 2, message = "薪资格式不正确")
private BigDecimal salary;
@Valid
@NotNull(message = "地址信息不能为空")
private Address address;
@Size(min = 1, message = "至少需要一个角色")
@Valid
private List<Role> roles;
// getters and setters
}
// 嵌套对象验证
public class Address {
@NotBlank(message = "省份不能为空")
private String province;
@NotBlank(message = "城市不能为空")
private String city;
@NotBlank(message = "详细地址不能为空")
@Size(max = 200, message = "详细地址不能超过200个字符")
private String detail;
@Pattern(regexp = "\\d{6}", message = "邮政编码必须是6位数字")
private String zipCode;
// getters and setters
}
// 控制器中使用验证
@RestController
@RequestMapping("/api/users")
public class UserController {
@PostMapping
public ResponseEntity<?> createUser(@Valid @RequestBody User user, BindingResult result) {
// 检查验证结果
if (result.hasErrors()) {
Map<String, String> errors = new HashMap<>();
result.getFieldErrors().forEach(error ->
errors.put(error.getField(), error.getDefaultMessage())
);
return ResponseEntity.badRequest().body(errors);
}
User savedUser = userService.save(user);
return ResponseEntity.status(HttpStatus.CREATED).body(savedUser);
}
@PutMapping("/{id}")
public ResponseEntity<?> updateUser(@PathVariable Long id,
@Valid @RequestBody User user,
BindingResult result) {
if (result.hasErrors()) {
return ResponseEntity.badRequest().body(getValidationErrors(result));
}
user.setId(id);
User updatedUser = userService.update(user);
return ResponseEntity.ok(updatedUser);
}
private Map<String, Object> getValidationErrors(BindingResult result) {
Map<String, Object> response = new HashMap<>();
Map<String, String> fieldErrors = new HashMap<>();
result.getFieldErrors().forEach(error ->
fieldErrors.put(error.getField(), error.getDefaultMessage())
);
List<String> globalErrors = result.getGlobalErrors().stream()
.map(ObjectError::getDefaultMessage)
.collect(Collectors.toList());
response.put("fieldErrors", fieldErrors);
response.put("globalErrors", globalErrors);
response.put("message", "验证失败");
return response;
}
}2. 自定义验证
java
// 自定义验证注解
@Target({ElementType.FIELD, ElementType.METHOD})
@Retention(RetentionPolicy.RUNTIME)
@Constraint(validatedBy = UniqueUsernameValidator.class)
public @interface UniqueUsername {
String message() default "用户名已存在";
Class<?>[] groups() default {};
Class<? extends Payload>[] payload() default {};
}
// 自定义验证器
@Component
public class UniqueUsernameValidator implements ConstraintValidator<UniqueUsername, String> {
@Autowired
private UserService userService;
@Override
public void initialize(UniqueUsername constraintAnnotation) {
// 初始化逻辑
}
@Override
public boolean isValid(String username, ConstraintValidatorContext context) {
if (username == null || username.trim().isEmpty()) {
return true; // 空值由 @NotBlank 处理
}
return !userService.existsByUsername(username);
}
}
// 复杂自定义验证
@Target({ElementType.TYPE})
@Retention(RetentionPolicy.RUNTIME)
@Constraint(validatedBy = PasswordMatchValidator.class)
public @interface PasswordMatch {
String message() default "密码和确认密码不匹配";
Class<?>[] groups() default {};
Class<? extends Payload>[] payload() default {};
String password();
String confirmPassword();
}
@Component
public class PasswordMatchValidator implements ConstraintValidator<PasswordMatch, Object> {
private String passwordField;
private String confirmPasswordField;
@Override
public void initialize(PasswordMatch constraintAnnotation) {
this.passwordField = constraintAnnotation.password();
this.confirmPasswordField = constraintAnnotation.confirmPassword();
}
@Override
public boolean isValid(Object obj, ConstraintValidatorContext context) {
try {
Object password = getFieldValue(obj, passwordField);
Object confirmPassword = getFieldValue(obj, confirmPasswordField);
return Objects.equals(password, confirmPassword);
} catch (Exception e) {
return false;
}
}
private Object getFieldValue(Object obj, String fieldName) throws Exception {
Field field = obj.getClass().getDeclaredField(fieldName);
field.setAccessible(true);
return field.get(obj);
}
}
// 使用自定义验证
@PasswordMatch(password = "password", confirmPassword = "confirmPassword")
public class UserRegistrationRequest {
@UniqueUsername
@NotBlank(message = "用户名不能为空")
private String username;
@NotBlank(message = "密码不能为空")
@Size(min = 8, message = "密码长度不能少于8位")
@Pattern(regexp = "^(?=.*[a-z])(?=.*[A-Z])(?=.*\\d).*$",
message = "密码必须包含大小写字母和数字")
private String password;
@NotBlank(message = "确认密码不能为空")
private String confirmPassword;
// getters and setters
}3. 验证组
java
// 验证组接口
public interface CreateGroup {}
public interface UpdateGroup {}
public interface DeleteGroup {}
// 使用验证组
public class User {
@NotNull(groups = {UpdateGroup.class, DeleteGroup.class}, message = "更新和删除时ID不能为空")
private Long id;
@NotBlank(groups = {CreateGroup.class, UpdateGroup.class}, message = "用户名不能为空")
@UniqueUsername(groups = CreateGroup.class)
private String username;
@NotBlank(groups = {CreateGroup.class}, message = "创建用户时密码不能为空")
@Size(min = 8, groups = {CreateGroup.class, UpdateGroup.class})
private String password;
@Email(groups = {CreateGroup.class, UpdateGroup.class})
private String email;
// getters and setters
}
// 控制器中使用验证组
@RestController
@RequestMapping("/api/users")
public class UserController {
@PostMapping
public ResponseEntity<?> createUser(@Validated(CreateGroup.class) @RequestBody User user,
BindingResult result) {
if (result.hasErrors()) {
return ResponseEntity.badRequest().body(getValidationErrors(result));
}
User savedUser = userService.save(user);
return ResponseEntity.status(HttpStatus.CREATED).body(savedUser);
}
@PutMapping("/{id}")
public ResponseEntity<?> updateUser(@PathVariable Long id,
@Validated(UpdateGroup.class) @RequestBody User user,
BindingResult result) {
if (result.hasErrors()) {
return ResponseEntity.badRequest().body(getValidationErrors(result));
}
user.setId(id);
User updatedUser = userService.update(user);
return ResponseEntity.ok(updatedUser);
}
@DeleteMapping("/{id}")
public ResponseEntity<Void> deleteUser(@Validated(DeleteGroup.class) @RequestBody User user) {
userService.delete(user.getId());
return ResponseEntity.noContent().build();
}
}4. 全局验证异常处理
java
@ControllerAdvice
public class ValidationExceptionHandler {
// 处理 @Valid 验证失败
@ExceptionHandler(MethodArgumentNotValidException.class)
public ResponseEntity<ValidationErrorResponse> handleValidationException(
MethodArgumentNotValidException ex) {
ValidationErrorResponse errorResponse = new ValidationErrorResponse();
errorResponse.setMessage("验证失败");
errorResponse.setTimestamp(LocalDateTime.now());
Map<String, String> fieldErrors = new HashMap<>();
ex.getBindingResult().getFieldErrors().forEach(error ->
fieldErrors.put(error.getField(), error.getDefaultMessage())
);
errorResponse.setFieldErrors(fieldErrors);
List<String> globalErrors = ex.getBindingResult().getGlobalErrors().stream()
.map(ObjectError::getDefaultMessage)
.collect(Collectors.toList());
errorResponse.setGlobalErrors(globalErrors);
return ResponseEntity.badRequest().body(errorResponse);
}
// 处理 @Validated 验证失败
@ExceptionHandler(ConstraintViolationException.class)
public ResponseEntity<ValidationErrorResponse> handleConstraintViolationException(
ConstraintViolationException ex) {
ValidationErrorResponse errorResponse = new ValidationErrorResponse();
errorResponse.setMessage("参数验证失败");
errorResponse.setTimestamp(LocalDateTime.now());
Map<String, String> violations = new HashMap<>();
ex.getConstraintViolations().forEach(violation -> {
String propertyPath = violation.getPropertyPath().toString();
String message = violation.getMessage();
violations.put(propertyPath, message);
});
errorResponse.setFieldErrors(violations);
return ResponseEntity.badRequest().body(errorResponse);
}
// 处理参数类型转换异常
@ExceptionHandler(MethodArgumentTypeMismatchException.class)
public ResponseEntity<ValidationErrorResponse> handleTypeMismatchException(
MethodArgumentTypeMismatchException ex) {
ValidationErrorResponse errorResponse = new ValidationErrorResponse();
errorResponse.setMessage("参数类型错误");
errorResponse.setTimestamp(LocalDateTime.now());
Map<String, String> fieldErrors = new HashMap<>();
fieldErrors.put(ex.getName(),
String.format("参数 '%s' 的值 '%s' 无法转换为 %s 类型",
ex.getName(), ex.getValue(), ex.getRequiredType().getSimpleName()));
errorResponse.setFieldErrors(fieldErrors);
return ResponseEntity.badRequest().body(errorResponse);
}
}
// 验证错误响应类
public class ValidationErrorResponse {
private String message;
private LocalDateTime timestamp;
private Map<String, String> fieldErrors;
private List<String> globalErrors;
// getters and setters
}视图解析
1. 视图解析器配置
java
@Configuration
@EnableWebMvc
public class ViewResolverConfig implements WebMvcConfigurer {
// JSP 视图解析器
@Bean
public ViewResolver jspViewResolver() {
InternalResourceViewResolver resolver = new InternalResourceViewResolver();
resolver.setPrefix("/WEB-INF/views/");
resolver.setSuffix(".jsp");
resolver.setViewClass(JstlView.class);
resolver.setOrder(3);
return resolver;
}
// Thymeleaf 视图解析器
@Bean
public SpringTemplateEngine templateEngine() {
SpringTemplateEngine engine = new SpringTemplateEngine();
engine.setTemplateResolver(templateResolver());
engine.setEnableSpringELCompiler(true);
// 添加方言
engine.addDialect(new SpringSecurityDialect());
engine.addDialect(new Java8TimeDialect());
return engine;
}
@Bean
public ITemplateResolver templateResolver() {
SpringResourceTemplateResolver resolver = new SpringResourceTemplateResolver();
resolver.setApplicationContext(applicationContext);
resolver.setPrefix("/WEB-INF/templates/");
resolver.setSuffix(".html");
resolver.setTemplateMode(TemplateMode.HTML);
resolver.setCacheable(false); // 开发环境设置为 false
resolver.setCharacterEncoding("UTF-8");
return resolver;
}
@Bean
public
